SuperImage Small Infrared Ray Tunn el Dryer
SuperImage Screen printing machine conveyor dryer
Infrared Ray Dryer
Tunnel/Conveyor Type Top Quality & Stability & Excellent Warranty This machine can be used in all kinds of overprint printing, especially the T-shirt screen printing. The bedplate is designed as a special desk for T-shirt, which is more convenient and more accurate for the screen printing t-shirt.The machine can also be used for garments, woven fabrics, pieces, bags, umbrellas, metal, paper, plastic, copybook, circuit, wood, glass, ceramic tiles and various planar screen printing products such as leather shrinkage deformation of large articles of multicolor overprint accuracy. The use of thermosetting ink, mucilage, and other materials printing.The front and back sides of the worktable can be moved, and the screen can be adjusted in front, left and right, rotating and fine-tuning, and the front end of the screen can be adjusted up and down. Orientation Chromatography is convenient and accurate. It can be widely used in silk screen printing of cloth, clothing, T-shirt and textile.
Make the drying function after screen printing for textile fabrice.
Scope of application: all screen printing fields in textile.
Main Features: 1. adopting new synchronous servo system, transmission speed and better stability.
2. the table automatically rotate each station positioning accuracy (± 0.05mm).
3. big dryer area.
4. even rotating speed.
5. easy to maintain, easy to operate.
6. the design of the whole machine is reasonable, simple and practical.
7. the whole machine adopts simple design, saving space, more convenient handling and migration;
8. adjustable temperature control exactly.
9. the machine adopts all metal structure, the body adopts advanced electrostatic spraying, the appearance is elegant, clean and convenient. The main installation parts are stainless steel materials.
10. Electronic continuously variable transmission, stable, reliable, long life and low noise.
11. Using the heating mode of quartz far infrared tube, the infrared radiation can be continuously produced when working, with the powerful wind cycle, the temperature of the heating room becomes more uniform and the electric energy is saved at the same time.
12.The transmission part adopts high-power DC motor, which can carry out stepless speed regulation and high load ratio.
13. It can work continuously for a long time and runs stably and reliably.
14. With special mechanical structure design, the appearance is more beautiful and luxurious, making maintenance easier and more convenient.
Basic Data and Specification:
| ITEM | SI-LP400 | SI-LP600 |
| MACHINE SIZE(L×W×H) | 1100*660*600mm | 1100*860*600mm |
| DRYING AREA(L×W×H) | 400*900mm | 600*900mm |
| CONVEYOR WIDTH | 400mm | 600mm |
| MAX.FEEDING HEIGHT | 100mm(ADJUSTABLE) | 100mm(ADJUSTABLE) |
| ADJUSTABLE TEMPERATURE | 0-300CELSUIS DEGREES | 0-300CELSUIS DEGREES |
| CONVEYOR BELT MATERIALS | TEFLON | TEFLON |
| CONVEYOR SPEED | 1~10m/min | 1~10m/min |
| CONVEYOR MOTOR POWER | 90W(CONTINUOUSLY VIABLE) | 90W(CONTINUOUSLY VIABLE) |
| HEATING TUBING | INFRARED RAY TUBINGS | INFRARED RAY TUBINGS |
| MAX.LOADING WEIGHT | 15KG | 15KG |
| MACHINE WEIGHT | 60KG | 60KG |
| MACHINE PACKING WEIGHT | 100KG | 100KG |
| WORKING POWER | 220V 50-60Hz/380V 50-60HZ | 220V 50-60Hz/380V 50-60HZ |
| RATED POWDER | 6KW | 6KW |
Quality Warranty: SuperImage affords full quality warranty for our infrared ray tunnel dryer products.
For any inferior quality products or loss caused by inferior products quality, SuperImage will be responsible for products-changing, returning and replacements delivery, as well as related compensation.
